| Smart Features |
Motion Detection 2.0, Human/Vehicle Analysis |
| Video Input |
16-ch IP Video Input |
| Incoming Bandwidth |
160 Mbps |
| Outgoing Bandwidth |
80 Mbps |
| HDMI Output |
1-ch, up to 4K (4096×2160/30Hz, 3840×2160/30Hz), 2K (2560×1440/60Hz), 1080p/60Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz |
| VGA Output |
1-ch, 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz |
| Video Output Mode |
HDMI/VGA simultaneous output |
| Audio Output |
1-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 kΩ) |
| Decoding Format |
H.265+, H.265, H.264+, H.264 |
| Recording Resolution |
8MP, 6MP, 5MP, 4MP, 3MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF |
| Synchronous Playback |
16-ch |
| Decoding Capability |
1-ch @ 8MP (30fps), 3-ch @ 4MP (30fps), 6-ch @ 1080p (30fps) |
| Resolution Limit |
Max width/height per channel: 4096 pixels |
| Remote Connection |
Up to 32 users |
| Network Protocols |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
| Network Interface |
1 × RJ-45 (10/100/1000 Mbps self-adaptive Ethernet) |
| SATA |
1 SATA Interface |
| Storage Capacity |
Up to 8 TB per disk |
| USB Interface |
2 × USB 2.0 |
| Power Supply |
12 VDC, 1.5 A |
| Power Consumption |
≤ 10 W (without HDD) |
| Working Temperature |
-10°C to 55°C |
| Working Humidity |
10% to 90% |
| Dimensions (W × D × H) |
320 × 240 × 48 mm |
| Weight |
≤ 1 kg (without HDD) |
