JAV 65″ Smart Board, Google EDLA Certified, 4K, 8+128GB Interactive Smart Board H18S
Key Feature of JAV 65″ Interactive Smart Board in Nepal
- 48MP HD Camera, 8-Array Microphone
- Specially Designed MediaTek Tech MT9679 Chipset
- Quad Core CPU Cortex A73*4
- GPU Mali G52*4
- Google EDLA certified
- Original A-grade panel, 4K resolution, 60 Hz refresh rate
- 8GB RAM + 128GB ROM
- Supports up to 40 points of touch
- Scratch Resistant, Anti Bacterial, Glass with level 7 of Mohs Standard
- Front physical buttons and interfaces
- Supports dual systems (Android and Windows/Linux)
- One-piece molding, simple and stylish
- Zero-bonding design
- Interval sound design
Short Description of JAV 65" Interactive Smart Board in Nepal
- 48MP HD Camera, 8-Array Microphone
- Specially Designed MediaTek Tech MT9679 Chipset
- Quad Core CPU Cortex A73*4
- GPU Mali G52*4
- Google EDLA certified
- Original A-grade panel, 4K resolution, 60 Hz refresh rate
- 8GB RAM + 128GB ROM
- Supports up to 40 points of touch
- Scratch Resistant, Anti Bacterial, Glass with level 7 of Mohs Standard
- Front physical buttons and interfaces
- Supports dual systems (Android and Windows/Linux)
- One-piece molding, simple and stylish
- Zero-bonding design
- Interval sound design
Specification of JAV 65″ Interactive Smart Board in Nepal
| Model | JAV H18S 65-inch |
| Display Parameters | |
| Display Area | 1429(H)×804(V) |
| Aspect | 16:09 |
| Resolution | 3840× 2160 Pixels |
| Backlight | DLED |
| Response Time | 6.5ms |
| Refreshing Frequency | 60Hz |
| NTSC(typ) | >72% |
| Display Color | 1.07B (10bit) |
| Brightness | ≥400cd/m2 |
| Contrast Ratio | Based on the OC |
| Viewing Angle | 178(H/V) |
| Technology | Zero bonding |
| Touch Parameters | |
| Sensing Type | lnfrared recognition |
| System | Windows10/Windows8/Windows7/WindowsXP Android/Linux/MacOSX/Chrome |
| Touch point | 40 points touch |
| Writing height | ≤1.5mm |
| Response Time | ≤5ms |
| Touch Tool | Finger,Passive infrared pen,Active infrared pen |
| Accuracy | ±1mm(over 90%Area) |
| Surface Hardness | Anti-bacteria,Anti-glare tempering glass. Toughened Glass with Level 7 of Mohs Standard |
| Output Coordinate | 32767×32767 |
| Camera and Microphone | |
| Camera | 48MP 1080P HD Camera with AI function |
| Microphone | 8 Array Microphone |
| System Parameters | |
| System Version | Android 14 |
| Chipset | MT9679 |
| CPU | Cortex-A73×4 |
| GPU | Mali-G52*4 |
| RAM/ROM | 8GB/128GB |
| I/O interfaces | |
| FRONT | Type-C (USB):1 HDMI:1 Touch:1 USB:3 |
| REAR | RS232:1 TOUCH:1 HDMI:1 RJ 45:1 USB 2.0:2 TF CARD:1 WIFI 5G:1 WIFI 2.4G:1 AC SWITCH:1 AC IN:1 COAXIAL:1 LINE OUT:1 |
| General Parameters | |
| Power Supply | 100-240V~50/60Hz |
| Overall Power | 175W |
| Overall Power | ≤0.5W |
| Speaker Type | 2.0 Sound channel |
| Output Power | 2×16W |
