JAV Smart Board 86 Inch, 4K 16+256GB Interactive Smart Board H12S-2
Key Features of JAV 86″ Interactive Smart Board in Nepal
- RAM 16G+ROM 256G
- 48 MP camera, 8 Array Microphone
- Original A-grade Panel With 4K UltraHD resolution
- 3588 Chipset, octa-core CPU, Android 13.0
- Support up to 50 touch points
- Front six-button design, rich functions, one-key direct access
- AI features
JAV 86" H12S-2 Interactive Smart Board Price in Nepal
- OS: Android 13.0
- Display: 4K UHD display with full channel 4K UI support, zero bonding technology, low optical parallax writing, wider viewing angle, anti-glare tempered glass
- Touch: ±1.5mm precision infrared touch, supports up to 50 touch points, ideal for smooth and accurate interaction on the Interactive Smartboard
- Camera & Mic: 48MP camera, 8-array microphone, enhancing collaboration and communication on the Interactive Smartboard
- Connectivity: Front ports (2 USB 3.0, 1 HDMI in, 1 Touch USB, 1 Type-C), NFC, Wi-Fi 6 (dual-frequency 2.4G/5G), wireless screen sharing, internet sharing
- Performance: 3588 chipset, octa-core CPU, 16GB RAM + 256GB storage, ensuring seamless performance for the Interactive Smartboard
- Extras: Super-narrow frame design, 2 stylus slots, 80PIN OPS support, gigabit Ethernet, front six-button design, wake-by-internet, all-in-one Net-Com
- Warranty: 3 Years
JAV 86″ H12S-2 Interactive Smart Board Specification |
|
| Panel Size | 86 Inch |
| Aspect | 16:9 |
| Display Area | 1649(H)x928(V) |
| Max Resolution | 3840×2160 Pixels |
| Back Light | D-LED |
| Response Time | <6ms |
| Refreshing Frequency | 100Hz |
| Display Color | 1.07B(10bit) |
| Brightness | >=450cd/m^2 |
| Contrast Ratio | Base on the OC |
| Viewing Angle | 178(H/V) |
| Anti-glare | Yes |
| Sensing Type | Infrared recognition |
| System | Windows 10/Windows 8/Windows 7/WindowsXP Android/Linux/MacOSX/Chrome |
| Touch Point | <=50 points touch,20 points writing |
| Minimum recognition | 2mm |
| Writing height | 3mm |
| Touch Tool | Finger, Passive Infrared Pen, Active Infrared pen |
| Response Time | <15ms |
| Accuracy | +-1mm(over 90% Area) |
| Surface Hardness | Toughened Glass with Level 7 of Mohs Standard |
| Output Coordinate | 32767×32767 |
|
Android System Parameters |
|
| System Version | Android 13 |
| Chipset | RK3588 |
| CPU | A55*4+A76*4 |
| GPU | Mali-G610*4 |
| RAM/ROM | 16GB/256GB |
| WiFi and Bluetooth | Support |
|
Android AIO interfaces |
|
| FRONT | Type-C(USB)-1 |
| HDMI IN-1 | |
| Touch-1 | |
| USB 3.0-2 | |
| REAR | TYPE C IN-1 |
| TYPE C OUT-1 | |
| TOUCH-2 | |
| USB 3.0-2 | |
| HDMI IN-3 | |
| HDMI OUT-1 | |
| DP IN-1 | |
| BOTTOM | LINE OUT-1 |
| RJ45 IN-1 | |
| RJ45 OUT-1 | |
| VGA-1 | |
| PC AUDIO-1 | |
| USB 2.0-1 | |
| COAX OUT-1 | |
| RS232-1 | |
| TOUCH-1 | |
|
General Parameters |
|
| Power Supply | 100-240V 50/60HZ |
| Overall Power | 353W |
| Standby Power | <=0.5W |
| Speaker Power | Two Sound Channel/
2.1 Sound Channel(optional) |
| Output Power | 2x10W/(Optional 2x10W) |
| Outline(mm) | 1953x1162x88 |
| Package(mm) | L2095xW160xH1290mm |
| Net(kgs) | 65.1Kg |
| Gross(kgs) | 82.65Kg |
| VESA(mm) | 600×400 |
| Working temperature | 0C-40C |
| Working Humidity | 10%RH-90%RH |
| Storage temperature | -20C-60C |
| Storage Humidity | 10%-90% |
|
Accessories |
|
| Standard | User Manual-1 |
| Power Cord-1 | |
| Stylus-2 | |
| Wall Mount Bracket-1 | |
| NFC Card-3 | |
| Remote Control-1 | |
| Optional | OPS PC-1 |
| HDMI Cable-1 | |
| Touch USB Cable-1 | |
| Mobile Floor Stand-1 | |
