| Product Information |
Product Type |
Ceiling AP |
| Hardware Specifications |
Radio Design |
Dual-radio |
|
Spatial Streams |
4 Spatial Streams |
|
2.4 GHz |
2 × 2 MIMO |
|
5 GHz |
2 × 2 MIMO |
|
Max Wireless Speed |
1266 Mbps |
|
6 GHz Support |
No |
|
5 GHz Speed |
866 Mbps |
|
2.4 GHz Speed |
400 Mbps |
| Antenna |
2.4 GHz |
2 Built-in Omnidirectional Antennas |
|
5 GHz |
2 Built-in Omnidirectional Antennas |
| Dimensions & Weight |
Size |
194 × 194 × 35 mm |
|
Color |
White |
|
Weight |
≤ 0.45 kg |
| Ports |
Ethernet Ports |
2 × 10/100/1000BASE-T |
| Power Supply |
Power Options |
DC Adapter / PoE / PoE+ |
|
Priority |
DC preferred over PoE/PoE+ |
|
DC Connector |
12V, 1.5A |
|
Connector Size |
5.5 mm (outer), 2.1 mm (inner), 10 mm depth |
|
Max Power Consumption |
12.95 W |
|
PoE Budget |
Not Supported |
| Environment |
Operating Temp |
0°C to 40°C |
|
Mounting |
Ceiling / Wall |
|
IP Rating |
Not Available |
| Software |
Max Clients (2.4 GHz) |
64 |
|
Max Clients (5 GHz) |
110 |
|
Total Clients |
110 |
|
Managed Devices |
Up to 300 |
|
IPv6 Support |
Yes |
